HP Compaq NC7131 Gigabit Ethernet NIC 10/100/1000Base-T PCI 64-bit/66MHz Card REF

ab 29,95 €
exkl. 19% USt., zzgl. Versand
  • sofort verfügbar
  • ArtikelNr.: 200908300
  • Artikelgewicht: 0,50 kg
  • Versandgewicht: 0,50 kg
Jetzt Kaufen
bitte wählen

Beschreibung

HP Compaq NC7131 Gigabit Ethernet NIC 10/100/1000Base-T PCI 64-bit/66MHz Card
Modell:
158575-B21
Zustand: refurbished, 12 Monate ip4 Gewährleistung

  • Manufacturer: HP Compaq
  • Part/Assembly Number(s): 223773-001
  • Option/Retail Part Number: 158575-B21
  • Spare Number(s): 161665-001
  • Compatible with Server Models: 8000, 8500, CL380, DL320 G1, DL360 G1, DL380 G1, DL380 G2, DL580 G1, DL590, DL760 G1, ML330 G1, ML350 G1, ML350 G2, ML370 G1, ML370 G2, ML530 G1, ML570 G1, ML750
  • Technical Specifications

    Compliance IEEE 802.3i, 802.3u, 802.3x, 802.3ab, 802.3ad (static configuration mode only), 802.1p, and 802.1Q
    PCI 2.2
    ACPI v1.20a compliant
    General Specifications Communications Processor
    On-board memory
    Data path
    Interrupt levels
    Bus architecture
    Connector
    Distance
    Wiring
    Dimensions
    (LxW)
    Intel 82543GC
    10/100/1000 Mbps, Half- and full-duplex
    64 KB
    64-bit/66MHz, compatible with 64/33 and 32/33
    INTA
    PCI bus-mastering
    RJ-45
    Up to 328 feet/100 meters
    CATegory 5 or higher UTP
    7 x 2.75 in/18 x 7.2 cm
      64-bit addresses for systems with more than 4 GB of physical memory
    64-bit PCI host interface compliant with PCI 2.2
    Command usage optimization for advanced PCI commands (MWI and memory reads)
    Software controlled global reset bit (resets everything except PCI configuration registers)
    Power and Environmental Specifications Operating Temperature 32° to 131°F/0° to 55°C
      Humidity 10% to 90%
    Non-operating Temperature -85° to 185°F/-65° to 85°C
      Humidity 5% to 95%
      Power requirement 1600 mA @ 5V maximum
      Emissions Standards FCC Class B, VCCI Class B, BSMI Class A, CISPR 22 Class B, EN60950,
    EN 55022 Class B, EN55024, UL, Canada UL, CES-003 Class B
      Safety Compliant CE Mark
    Operating System Support Windows 2000
    Windows NT 4.0
    Novell NetWare 4.x, 5.x Server
    SCO UnixWare 7.x
    SCO OpenServer 5.x
    Linux Red Hat 7.x
    MS-DOS Client for unattended installation

    Software Feature Support by Operating System FEATURE Windows 2000 Windows NT 4.0 Linux
    32-bit
    UnixWare 7.x Open Server 5.x NetWare 4.11 Server NetWare 5.0 Server
      NFT * *   * * * *
      Link Aggregation * *       * *
      PCI
    Hot-Plug
    * *       * *
      Configuration and Diagnostics * *
      DMI 2.0 * *       * *
      SNMP * * *     * *
      SmartStart * * * * * * *
      WBEM * * * * * * *


    Insight Manager
    Insight Manager XE

    * * * * * * *
      IML * * * * *

    Kit Contents

    NC7131 Gigabit Server Adapter
    CD containing Drivers, User Guide, and Installation and Diagnostic Utilities
    Quick Install Card
    Product Quality Statement
    Product Warranty Statement

    Warranty Maximum: The remaining warranty of the Compaq server product in which it is installed (to a maximum of a three-year limited warranty).
      Minimum: One-year, on-site limited warranty.
      NOTE: Certain restrictions and exclusions apply. In North America, call 1-800-OK-COMPAQ; outside of North America, please contact your customer service center.

    Eigenschaften

    • Zustand: Es handelt sich um Gebrauchtware, welche von unserem Technikerteam getestet wurde. Die Ware ist technisch und optisch in einem einwandfreien Zustand, jedoch können teilweise Gebrauchtspuren zu sehen sein, inkl. 12 Monate ip4 Gewährleistung.
